Sunsynk Loadshedder 4 (All in one 3.6kW Hybrid inverter and 3.84kWh Lithium Battery)

Description

The Loadshedder 4 is a highly efficient all in one 3.6kW Hybrid inverter and 3.84kWh Lithium battery masterfully crafted by Sunsynk to simplify and speed up installation. The Loadshedder 4 manages power-flow from multiple sources such as solar, mains power (grid) and
generators, and then effectively stores and releases power as and when required.

Up to three (3) Loadshedder 4 units can be installed in parallel configuration, and you can also add additional external Sunsynk batteries to increase the battery capacity with a maximum of 6 additional external Sunsynk batteries for three (3) Loadshedder 4 units in parallel.

INTERACTIVE

Easy and simple to understand LCD display.
Supporting Wi-Fi or GSM monitoring.
Built-in MPPT trackers.
Smart settable 3-stage MPPT charging for optimised battery performance.

COMPATIBLE

Compatible with main electrical grid voltages.
230V single-phase, pure sine wave inverter.

CONFIGURABLE

Fully programmable controller.
Programmable supply priority for battery or grid.
Programmable multiple operation modes: on-grid / off-grid & UPS.
Configurable battery charging – current / voltage based on the application.

SECURE

Overload / over-temperature / short-circuit protection.
Smart battery charger design for optimized battery protection.
Limiting function installed to prevent excess power overflow to grid.

APPLICATIONS

Power shedding (home / office / factory).
UPS (Uninterrupted Power Supply).
Remote locations with solar.
Building sites.
Telecommunication.

Datasheet:Loadshedder 4

Installation manual: SunsynkMobile_SM2.5kWLS_Parallel_v14
